The Brennan Industries #4 JIC Tube Nut is a straight hydraulic fitting made from high-quality stainless steel for superior corrosion resistance. It features a 7/16-20 JIC thread per SAE J514 standards and a compact design with a 0.61"" overall length. With a 0.562"" hex size and 0.03 lbs weight, it's ideal for durable, high-pressure hydraulic connections in demanding environments
- 7/16-20 JIC thread per SAE J514 specification
- Made from corrosion-resistant stainless steel
- Compact size with 0.61" overall length
- 0.562" hex size for easy installation
- Lightweight at just 0.03 lbs
| Thread B1 Type | Jic Tube Nut |
| Thread B1 Size | 7/16-20 |
| Thread B1 Drill In | 0.304 |
| Thread B1 Specification | Sae J514 |
| C Hex 1 in. | 0.562 |
| Overall Length L in. | 0.61 |
| Shape | Straight |
| Body Material | Stainless Steel |
| Raw Material Type | Straight Stainless Steel |
| Weight | 0.03 Lbs |
| California Residents | Prop-65 Warning |
| Cubic in. (L W H) | 0.196 |
