The BuTech 20BC9 ball check valve is engineered for one-way flow in medium-pressure tubing systems, ensuring smooth operation up to 20,000 psi. Featuring a 316 stainless steel body and a 17-4PH poppet, it delivers reliable metal-to-metal seating without elastomeric seals—perfect for high-temperature applications. The valve comes with a stainless steel spring to ensure consistent reseating and prevent backflow under pressure. Compact and robust, it seamlessly integrates into instrumentation panels, testing rigs, and fluid systems where durability and tight performance are critical. Ideal for industrial, petrochemical, and research environments demanding dependable flow control.
- Prevents reverse flow up to 20,000 psi in 9/16" tube systems
- Built with 316 stainless steel body and 17-4PH poppet
- Metal-to-metal seat requires no O-ring for high-temperature use
- Stainless steel spring ensures reliable reseating
- Compact size supports tight installations in test or instrumentation panels
| Model | 20BC9 |
| Valve Type | 2-Way Ball Check Valve (Tube × Tube) |
| Tube Connection | 9/16" OD tubing |
| Maximum Pressure | 20,000 psi (1,380 bar) |
| Cv | 2.30 |
| Dimensions (L × B × C × D) | 4.22" × 3.50" × 1.38" × 1.38" |
| Material | Body: 316 Stainless Steel; Poppet: 17‑4PH Stainless Steel; Spring: Stainless Steel |
| Cracking Pressure | ~15 psi (standard); configurable up to 100 psi |
| Temperature Range | –420 °F to +1,200 °F (–251 °C to +648 °C) |
| Seat Type | Metal-to-Metal |
| Finish | Polished Stainless Steel |
