The Stewarts USA 23B-V30-FP is a rugged 2.5" front-flange panel-mount pressure gauge featuring a stainless steel case and brass internal components. Designed with a glycerin fill, it effectively dampens pulsation and vibration for stable, accurate readings. The triple-scale dial displays vacuum to pressure ranges and includes PSI, BAR, and kPa measurements. Engineered to ASME B40.1 standards, this gauge is ideal for industrial, HVAC, and fluid power applications where reliability and readability matter. The stainless case ensures corrosion resistance, making it suitable for harsh environments.
- Stainless steel casing with brass internals for durability and corrosion resistance
- Glycerin-filled to absorb shock and provide smooth pointer movement
- Triple-scale dial (PSI/BAR/kPa) supports a wide range of measurements
- Front flange panel-mount configuration ensures secure, flush installation
- Built to ASME B40.1 Grade B accuracy and ISO 9001 quality standards
| Model | 23B-V30-FP |
| Dial Diameter | 2.5" (63?mm) |
| Case Material | Stainless steel |
| Internals | Brass socket, tube, movement |
| Connection | 1/4" NPT male (bottom) |
| Mounting Style | Front flange panel mount (FP) |
| Filling | Glycerin-filled for vibration damping |
| Dial Scale | PSI, BAR, kPa (triple-scale) |
| Accuracy | ASME B40.1 Grade B |
| Range | Vacuum 30?inHg to 0, and negative-to-positive ranges |
