The Brennan 5000-08-04-SS is a high-quality 1/2" FNPT x 1/4" FNPT straight stainless steel reducing coupling designed for demanding hydraulic and fluid transfer applications. Manufactured with precision SAE J476 NPTF threads, it ensures a tight, leak-free seal even under high pressure. Constructed from premium straight stainless steel, this fitting offers superior corrosion resistance and longevity in harsh industrial environments. With a pressure capacity of up to 5000 PSI, it is ideal for connecting different NPTF thread sizes in high-performance fluid systems. A strong, durable, and reliable choice for both commercial and industrial use.
Fitting Chart- 1/2" FNPT x 1/4" FNPT straight reducing coupling for hydraulic and fluid systems
- Precision SAE J476 NPTF threads ensure leak-proof, high-pressure sealing
- Built from premium stainless steel for exceptional corrosion resistance
- Rated for maximum dynamic pressure of 5000 PSI
- Strong 1.125" hex body allows secure tightening and installation
- Ideal for high-pressure hydraulic lines, industrial machinery, and fluid transfer equipment
| Thread B1 Type | Female NPTF |
| Thread B1 Size | 1/2-14 |
| Thread B1 Drill In | 0.531 |
| Thread B1 Specification | SAE J476 |
| Thread B2 Type | Female NPTF |
| Thread B2 Size | 1/4-18 |
| Thread B2 Drill In | 0.281 |
| Thread B2 Specification | SAE J476 |
| Body Hex In | 1.125 |
| Overall Length L In | 1.5 |
| Shape | Straight |
| Body Material | Stainless Steel |
| Raw Material Type | Straight Stainless Steel |
| Weight Lbs | 0.28 |
| Maximum Dynamic Pressure Psi | 5000 |
| California Residents | Prop-65 Warning |
| Cubic Inch Space L X W X H | 1.898 |
