This straight hydraulic fitting is designed for efficient size reduction, featuring a 1/2" MNPT (Male NPTF) thread on one end and a 1/4" FNPT (Female NPTF) thread on the other. Crafted from robust steel with a protective Cr3 plating, it delivers exceptional durability and superior resistance to corrosion in various hydraulic environments. Engineered for demanding applications, this fitting can reliably operate under a maximum dynamic pressure of 6000 psi. Its practical dimensions, including a 0.875" body hex and 1.1" overall length, ensure easy and secure integration into your system.
- Specific Male Thread: Features a 1/2-14 Male NPTF connection for primary input
- Specific Female Port: Includes a 1/4-18 Female NPTF port for reduced output or connection
- SAE J476 Compliant: Manufactured to SAE J476 specifications ensuring reliable threading
- Optimized Body Hex: The 0.875" hex body provides excellent grip for installation tools
- Compact 1.1" Length: Its short overall length is beneficial for installations in tight spaces
| Thread B1 Type | Male NPTF |
| Thread B1 Size | 1/2-14 |
| Thread B1 Drill In | 0.531 |
| Thread B1 Specification | SAE J476 |
| Thread B2 Type | Female NPTF |
| Thread B2 Size | 1/4-18 |
| Thread B2 Drill In | 0.281 |
| Thread B2 Specification | SAE J476 |
| Body Hex In | 0.875 |
| Overall Length L In | 1.1 |
| Shape | Straight |
| Body Material | Steel |
| Raw Material Type | Straight Steel |
| Plating | Cr3 |
| Weight Lbs | 0.1153 |
| Maximum Dynamic Pressure Psi | 6000 |
