This straight hydraulic fitting functions as a robust reducer, featuring a 1" MNPT (Male NPTF) thread on one end and a 1/4" FNPT (Female NPTF) thread on the other. It is engineered to seamlessly connect components of different sizes within hydraulic systems. Constructed from durable steel and protected by Cr3 plating, it ensures exceptional longevity and superior resistance to corrosion. Capable of withstanding a maximum dynamic pressure of 3000 psi, this fitting is suitable for various industrial applications. Its efficient design, including a 1.375" body hex and 1.36" overall length, allows for secure and space-conscious integration.
- Size Reducing Connector: Adapts 1" Male NPTF to 1/4" Female NPTF for system versatility
- Heavy-Duty Steel Build: Provides strong and reliable performance in demanding environments
- Corrosion-Resistant Cr3 Plating: Ensures extended lifespan by resisting rust and wear
- 3000 psi Pressure Rating: Designed to handle significant dynamic pressure in hydraulic circuits
- Compact Straight Form: Facilitates efficient installation in confined or in-line applications
| Thread B1 Type | Male NPTF |
| Thread B1 Size | 1-11-1/2 |
| Thread B1 Drill In | 0.907 |
| Thread B1 Specification | SAE J476 |
| Thread B2 Type | Female NPTF |
| Thread B2 Size | 1/4-18 |
| Thread B2 Drill In | 0.281 |
| Thread B2 Specification | SAE J476 |
| Body Hex In | 1.375 |
| Overall Length L In | 1.36 |
| Shape | Straight |
| Body Material | Steel |
| Raw Material Type | Straight Steel |
| Plating | Cr3 |
| Weight Lbs | 0.44 |
| Maximum Dynamic Pressure PSI | 3000 |
| California Residents | Prop-65 Warning |
| Cubic in. (L × W × H) | 2.571 |
