The 1" MNPT x 1/2" FNPT Stainless Steel Straight Adapter from Brennan Industries of Texas is designed for high-pressure hydraulic and industrial fluid connections. Featuring 1-11.5 Male NPTF threads paired with 1/2-14 Female NPTF threads, both built to SAE J476 standards, this fitting ensures precise, leak-free performance. Manufactured from high-quality stainless steel, it offers superior durability and corrosion resistance, even in harsh or chemical-prone environments. With a 3000 PSI dynamic pressure rating, it supports a wide range of demanding applications. The compact straight design and 1.375" hex allow easy installation in tight system layouts.
Fitting Chart- 1" Male NPTF to 1/2" Female NPTF stainless steel straight adapter
- Built to SAE J476 thread specifications for secure sealing
- Premium stainless steel construction for excellent corrosion resistance
- Rated for up to 3000 PSI dynamic pressure
- Compact design with 1.375" body hex for easy tightening
- Ideal for hydraulic, industrial, chemical, and high-pressure fluid systems
| Thread B1 Type | Male NPTF |
| Thread B1 Size | 1-11-1/2 |
| Thread B1 Drill In | 0.907 |
| Thread B1 Specification | SAE J476 |
| Thread B2 Type | Female NPTF |
| Thread B2 Size | 1/2-14 |
| Thread B2 Drill In | 0.531 |
| Thread B2 Specification | SAE J476 |
| Body Hex In | 1.375 |
| Overall Length L In | 1.36 |
| Shape | Straight |
| Body Material | Stainless Steel |
| Raw Material Type | Straight Stainless Steel |
| Weight Lbs | 0.353 |
| Maximum Dynamic Pressure Psi | 3000 |
| California Residents | Prop-65 Warning |
| Cubic Inch Space L X W X H | 2.571 |
