This straight hydraulic fitting acts as a robust reducer, featuring a 1" MNPT (Male NPTF) thread on one end and a 3/4" FNPT (Female NPTF) thread on the other. It is engineered to seamlessly connect components of different sizes within hydraulic systems. Constructed from durable steel and protected by Cr3 plating, it ensures exceptional longevity and superior resistance to corrosion. Capable of withstanding a maximum dynamic pressure of 3000 psi, this fitting is suitable for various industrial applications. Its efficient design, including a 1.375" body hex and 1.36" overall length, allows for secure and space-conscious integration
- Threaded Reducer Functionality: Connects 1" Male NPTF to 3/4" Female NPTF for size adaptation
- Durable Steel Construction: Provides robust strength and extended service life
- Corrosion-Resistant Cr3 Plating: Enhances durability by protecting against environmental wear
- 3000 psi Max Dynamic Pressure: Capable of handling moderate to high-pressure hydraulic demands
- Compact Straight Form Factor: Facilitates straightforward installation in space-constrained areas
| Thread B1 Type | Male NPTF |
| Thread B1 Size | 1-11-1/2 |
| Thread B1 Drill In | 0.907 |
| Thread B1 Specification | SAE J476 |
| Thread B2 Type | Female NPTF |
| Thread B2 Size | 3/4-14 |
| Thread B2 Drill In | 0.719 |
| Thread B2 Specification | SAE J476 |
| Body Hex In | 1.375 |
| Overall Length L In | 1.36 |
| Shape | Straight |
| Body Material | Steel |
| Raw Material Type | Straight Steel |
| Plating | Cr3 |
| Weight Lbs | 0.18 |
| Maximum Dynamic Pressure PSI | 3000 |
| California Residents | Prop-65 Warning |
| Cubic in. (L × W × H) | 2.571 |
