The BuTech 60F4 is a high-pressure coupling‑union designed to join two 1/4" high-pressure tubing ends safely and securely. Manufactured from 316 cold-worked stainless steel, it offers excellent corrosion resistance and structural strength for demanding environments. Rated to withstand pressures up to 60,000 psi, it ensures leak-tight integrity in critical fluid and gas systems. Compact and polished, the coupling integrates seamlessly into instrumentation frameworks, hydraulic test benches, and high-pressure manifolds. The simple union-style design allows for easy assembly and disassembly without compromising system performance.
- Joins two 1/4" high-pressure tubing securely
- Rated for ultra-high pressure up to 60,000 psi
- Machined from 316 cold-worked stainless steel
- Compact, polished design for tight installations
- Easy to assemble/disassemble with union-style coupling
- Ideal for instrumentation, manifolds, and test benches
| Model | 60F4 |
| Type | Coupling-Union (Tube × Tube) |
| Tube Size | 1/4" OD (High-Pressure) |
| Material | 316 Cold-Worked Stainless Steel |
| Maximum Pressure | 60,000 psi (4,136 bar) |
| Temperature Range | –18 °C to +315 °C (0 °F to +600 °F) |
| Finish | Polished Stainless Steel |
| Connection Style | Female Union-Style |
