This professional 90-degree miniature swivel elbow adapts a fine 1/8" push-in tube line to a 10-32 UNF male thread. Designed for precise routing in complex machinery, its 360-degree rotational axis allows for perfect orientation post-installation, eliminating tube bending and kinking.
Equipped with an integrated thread sealing ring and durable brass collet, it ensures dependable, leak-free directional routing in confined control grids.
- Full 360-degree mechanical swivel base allows for optimal tube line routing after final tightening
- Rigid push-in lock collar handles ultra-fine 1/8-inch tube outer diameters with absolute zero micro-slippage
- Fine-threaded 10-32 UNF male interface features an integrated O-ring for immediate air-tight port sealing
- Nickel-plated structural brass construction resists stress fractures, impact shocks, and UV fatigue
- Premium-elastomer Buna-N seals maintain an airtight lock along the rotating mechanical swivel connection
- Right-angle layout facilitates neat, close-cropped line positioning against cylinder bodies
| Item ID | 6522-02-32 |
| Product Type | Swivel Male 90° Elbow Fitting |
| Connections | 1/8" Tube X 10/32" UNF |
| Supplier Name | Camozzi Automation, Inc. |
| Application | Compact Multi-Axis Robotics and Dynamic Tool Plumbing |
| Kit Function | 90-Degree Adjustable Directional Path Routing |
| Compatibility | Standard 1/8" OD Polymer Tubing |
| Installation Type | Threaded Male Swivel and Push-In Connection |
| Compatible Media | Compressed Air and Inert Industrial Gases |
| Material | All-Metal Nickel-Plated Brass Shell with Elastomer Face Seal |
| Pressure Rating | Max 232 PSI / Vacuum up to 28" Hg |
