Ultra-Fast Response: 5–10 ms response time for high-speed applications.
Long Life Cycle: Rated for over 1 billion cycles in ideal conditions.
Compact & Durable: Nickel-plated brass and stainless-steel construction; weighs only 0.17 lbs.
Low Power Consumption: Operates at just 0.67 Watts with a coil resistance of 864 ohms.
Precision Control: 3-way, universally ported valve with 0.1 sccm leak rate and 0.007" poppet
- Ultra-Fast Response: 5–10 ms response time for high-speed applications.
- Long Life Cycle: Rated for over 1 billion cycles in ideal conditions.
- Compact & Durable: Nickel-plated brass and stainless-steel construction; weighs only 0.17 lbs.
- Low Power Consumption: Operates at just 0.67 Watts with a coil resistance of 864 ohms.
- Precision Control: 3-way, universally ported valve with 0.1 sccm leak rate and 0.007" poppet
| Accessories | Installation Socket Torque Tool 30215 |
| Coil Resistance | 864 |
| Connection Terminal | Pin, 0.025 in. |
| Connector | C2-Rb18 |
| Current | 0.028 A |
| Data Sheet | Data Sheet |
| Filtration | 40 Micron (Recommended) |
| Function | 3-Way Universally Ported |
| Leak Rate | 0.1 Sccm |
| Length | 1.81 in. |
| Life Cycle | >1,000,000,000 (Ideal Applications) |
| Material, Body | Nickel-Plated Brass, ENP Carbon Steel, Nickel Iron Alloy, 300 Stainless Steel |
| Material, Seals | Nitrile |
| Material, Spring | Nickel Alloy |
| Material, Wetted | ENP Brass, Nickel Alloy, Stainless Steel & ENP Steel |
| Max PSI | 105 |
| Max. Flow | 17 L/Min @ 100 PSIG |
| Medium | Clean, Dry Air & Compatible Gases |
| Mount | In-Line |
| Mounting | #6-32 Thread |
| Operating Pressure | 105 PSIG (17 L/Min @ 100 PSIG) |
| Operating Temperature Range | 32 to 180°F (0 to 82°C) |
| Operating Voltage Range | 90 to 150% |
| Poppet Travel | 0.007 in. |
| Port Size | #10-32 Female In-Line |
| Product Line Brochure | Spider Valves |
| Response Time | 5 to 10 Milliseconds (Nominal) |
| Unit | Imperial |
| Voltage | 24 VDC |
| Wattage | 0.67 Watts (Nominal) |
| Weight (lbs.) | 0.17 |
| Wire Connector | AMP #103959-1 |
