KQ2H11-35AS

The SMC KQ2H11-35AS is a compact and reliable one-touch male elbow fitting designed for efficient connection of 3/8 tubing to 1/4 NPT threaded ports. Featuring a durable brass construction with pre-applied thread sealant, this fitting ensures a leak-proof and secure installation in pneumatic systems. The KQ2 series is known for its quick-connect design, allowing for easy tube insertion and removal without damage. Ideal for use in tight spaces, the swivel stud enables effortless alignment during installation. Compatible with both nylon and polyurethane tubing, it supports a wide range of pressures from low vacuum up to 1.0 MPa making it suitable for a variety of industrial and automation applications.

• Wide Pressure Range: Suitable from low vacuum up to 1.0 MPa.
• One-Touch Connection: Easy push-to-connect system for rapid setup.
• Easy Disconnection: Special release collar allows removal of tubing without damage.
• Swivel Stud Design: Enables rotation of body for easier installation in tight spaces.
• Tube Compatibility: Accepts nylon and polyurethane tubing.
• Built-in Sealant: Threads come pre-coated with sealant for leak-free connections.
• Durability: Made with brass threads and NBR O-rings for robust performance.
• Non-Potable Use: Not intended for potable water applications.
