This 1/2 in. Tube O.D. x 1/4 in. MNPT Male Connector is a high-end, corrosion-resistant double ferrule compression tube fitting made of 316 stainless steel. For high-performance and high-pressure applications, it guarantees a torque-free, leak-proof seal that is perfect for crucial process and instrumentation systems.
It works well in sectors like chemical processing, petroleum, power generation, and pulp and paper. It can tolerate extreme temperatures between -198C and 648C (-325F and 1200F), with a maximum operating pressure of 11,000 psi (757 bar) at 100F (38C).
For long-term dependability, the double ferrule design provides increased grip strength and vibration resistance.
- 316 stainless steel is used for its exceptional strength and resistance to corrosion.
- Type of Connection: 1/4 in. x 1/2 in. NPT Tube O.D.
- Design: Double ferrule compression for a tight, impenetrable closure
- Maximum Operating Pressure: 100F (38C) at 11,000 psi (757 bar)
- Range of Temperature: -325F (-198C) to 1200F (648C)
- Applications include chemical, manufacturing, power, petroleum, and cryogenic systems.
- Compliance: stress ratings according to ASME B31.3-1999
- Note: Compared to female ends of the same size, male pipe ends can withstand greater pressure.
Type | Tube Fittings / Compression Fittings |
Product Type | Male Connector |
Material | 316 Stainless Steel |
Design | Double Ferrule |
Weight | 0.15 lbs |
End Connection | Tube O.D. Male NPT Threads |
Dimensions | 0.500 in (1/2) |
Measurements | 0.250 in (1/4) |
Operating Pressure | 11,000 psi (757 bar) @ 100F |
Temperature Range | -325F to 1200F |
Supported Dimensions | OD 1/16" to 2", OD 2 mm to 38 mm |
Style | Double Ferrule Compression Tube Fittings |
