The BuTech KW204-17-17 is a precision-engineered 2-way floating ball valve designed for medium-pressure applications with 9/16" MP tube connections. Machined from durable 316 cold-worked stainless steel, it maintains leak-tight performance up to 20,000 psi. Featuring pressure-loaded seats and a blowout-proof stem, it ensures long-term reliability and operator safety. The quarter-turn lever handle delivers intuitive on/off control with clear visual indication of flow status. Compact and modular, it easily fits instrumentation panels, hydraulic manifolds, and test rig assemblies.
- Rated for up to 20,000 psi in medium-pressure tubing systems
- Durable 316 stainless steel body resists corrosion
- Pressure-loaded seats deliver tight sealing under pressure
- Blowout-proof stem enhances operational safety
- Quick quarter-turn lever provides visual flow control
- Compact 9/16" MP tube ends ensure panel compatibility
| Model | KW204-17-17 |
| Valve Type | 2-Way Floating Ball Valve |
| Connections | 9/16" OD Medium-Pressure Tube × Tube |
| Max Pressure | 20,000 psi (1,380 bar) |
| Material | 316 Cold‑Worked Stainless Steel Body; 17-4PH Stem |
| Port / Cv | 9/16" Port with Cv ≈ 3.40 |
| Temperature Range | –20 °F to +400 °F (Up to +550 °F with High-Temp Seals) |
| Handle | Manual Quarter-Turn Lever |
| Stem & Seats | Blowout-Proof Stem with Pressure-Loaded Seats |
