The Haskel MHP-21 is a compact, manually operated version of the M-Series liquid pump designed for clean, controlled hydraulic applications. With a 21:1 ratio (actual around 25:1), it delivers up to 2,600?psig using manual leverage rather than air, ideal for portable pressure testing, calibration setups, or small-volume fluid transfer. The spring-return mechanism includes a stall-at-pressure feature holding preset pressure without additional pumping. Constructed from stainless/plated steel and PTFE/Buna-N seals, it's built for easy maintenance. It s an excellent choice where power or compressed air isn't available.
- Manual lever drive no air or electricity needed, ideal for field service or bench-top use
- Maximum pressure: 2,600?psig / 179?bar
- Displacement: ~0.20?in (3.3?mL) per stroke
- Stall-at-pressure function holds pressure without further effort
- Durable stainless/plated steel construction with PTFE/Buna-N seals
| Model | MHP-21 |
| Drive Type | Manual Hand Pump |
| Ratio | 21:1 Nominal (??25:1 Actual) |
| Max Pressure | 2,600?psig / 179?bar |
| Displacement | 0.20?in per stroke (~3.3?mL) |
| Weight | ~9?lb / 4.1?kg |
| Ports |
Inlet: 3/8" NPT Outlet: 1/4" NPT |
