This professional-grade sub-miniature air pilot valve is engineered to provide high-speed, crisp directional actuation within compact pneumatic logic networks. Machined from premium, wear-resistant metallic components, its robust body handles millions of continuous high-speed cycles without structural degradation or shifting delays. The highly responsive internal poppet design ensures minimal air usage and maximum shifting speed.
Designed for convenient base or manifold mounting layout configurations, this miniature valve dramatically lowers layout complexity inside dense automation control blocks. Its tight mechanical interfaces ensure reliable sealing, keeping system operations safe and highly predictable. This durable pilot valve provides consistent tool-free reliability and an exceptionally long, trouble-free service life.
- Tough premium machined brass body ensures complete mechanical stability and resists stripping under continuous industrial use.
- High-response internal poppet assembly delivers exceptionally rapid switching times, optimizing downstream mechanical cycle synchronization.
- Low-friction synthetic elastomer seals ensure reliable operation after long periods of line inactivity, stopping stickiness.
- Sub-miniature compact footprint permits clean integration into custom logic blocks, manifold arrays, and tight panels.
- Standardized threaded port configurations facilitate straightforward component replacement, minimizing plant routine maintenance times.
- Precision balanced design eliminates unexpected shifting failures under volatile system pressure drops, reinforcing facility safeties.
- Heavy-duty internal springs handle exceptionally high cycling frequencies, minimizing total equipment ownership costs over cycles.
| Part No | MPA-3P |
| Product Type | Air Valve |
| Supplier Name | Clippard Instrument Laboratory, Inc. |
| Application | Micro-pneumatic logic systems, piloting controls, and high-density automation panels |
| Function | 3-way normally closed directional flow switching via remote air pilot signals |
| Compatibility | Miniature pneumatic cylinders, analytical instrumentation networks, and standardized manifold sub-bases |
| Installation Type | Direct threaded connection or integrated manifold multi-station gang mounting layouts |
| Compatible Media | Clean, dry filtered compressed air and non-corrosive technical instrument gases |
| Material | Machined brass body structure paired with stainless steel springs and Buna-N seals |
| Operating Condition | High-frequency laboratory or factory automation processes subject to tight space constraints |
| Performance Feature | Exceptionally low actuation pressure thresholds balanced with ultra-fast sub-millisecond shifting speeds |
