This premium 90-degree swivel elbow fitting combines a rugged male NPT pipe thread connection with a quick push-in tube port for efficient directional routing. Manufactured with a high-strength technical polymer body and a robust metallic base, it offers exceptional resistance to mechanical wear, high pressures, and tough operating conditions. The integrated swivel joint permits complete 360-degree rotational freedom for easy alignment during machine plumbing.
Designed to eliminate fluid turbulence, this elbow fitting prevents pressure drops across sharp turns, ensuring constant power delivery to pneumatic cylinders. Its space-saving design is perfect for connecting lines in tight spaces. This durable swivel elbow simplifies maintenance, prevents line kinking, and ensures long-term leak-free reliability.
- Impact-resistant composite body ensures outstanding structural durability and long-term fatigue protection in demanding factory automation settings.
- Smooth right-angle interior profile eliminates restrictive fluid turbulence, ensuring maximum volumetric efficiency for pneumatic actuators.
- High-tensile gripping ring secures flexible lines firmly, preventing dangerous tube slip-outs under sudden pressure shocks.
- Integrated 360-degree swivel mechanism permits easy orientation alignment during assembly, simplifying tricky tube routing paths.
- Pre-coated male threads speed up structural assembly, ensuring a reliable leak-proof seal without extra tape labor.
- Advanced internal sealing rings maintain full pressure containment, minimizing energy losses and enhancing plant safety.
- Miniature space-saving envelope allows closer component grouping, maximizing productivity per square inch of control panel.
| Part No | P6520-53-04 |
| Product Type | 5/32" TUBE X 1/4" MNPT SWVL, ELBOW 90 |
| Supplier Name | Camozzi Automation, Inc. |
| Application | Branch circuit plumbing and port extensions on miniature pneumatic valve manifolds |
| Function | Right-angle adaptation of a female 1/4-inch NPT port to 5/32-inch flexible tubing |
| Compatibility | Standard fractional 5/32-inch outside diameter polymer lines and 1/4-inch female NPT ports |
| Installation Type | Threaded male NPT base with an instantaneous push-in tube port |
| Compatible Media | Industrial compressed air, non-corrosive system gases, and vacuum pressures |
| Material | Nickel-plated brass threaded base, technical polymer elbow body, and NBR seals |
| Operating Condition | High-speed automation applications subject to continuous cyclic motion and tight space constraints |
| Performance Feature | 360-degree rotational freedom for optimal orientation without compromising thread sealing integrity |
