Tylok® CBC-Lok® Bulkhead Female Connector, Double Ferrule, Series: DBHFP, Fitting/Connector Type: Connector, 3/8 in Nominal Size, Tube x FNPT, 316 Stainless Steel, Domestic.
CBC-Lok® tube fittings are fully interchangeable with Swagelok® and Parker A-Lok®. Although it is always recommended to use all CBC-Lok® components, intermixing CBC-Lok® bodies and/or component parts with that of other manufacturers will not adversely affect sealing ability. CBC-Lok® Tube Fittings are made to strict quality control standards. CBC-Lok® Tube Fittings are proudly made in the U.S.A.
- Double-ferrule CBC-Lok® compression system ensures reliable tube sealing
- 3/8″ Tube × 3/8″ FNPT female bulkhead interface with included lock nut
- Panel-mount ready: jam nut for secure panel or wall installation
- Fully interchangeable with Swagelok® and Parker A-Lok® fittings
- Precision-machined 316 stainless steel components, US-made
- Rated for -20 °F to 1000 °F temperature range
| Brand | Tylok® |
| Manufacturer Name | Tylok International |
| Tube Size | 3/8" |
| Thread Type | 3/8" FNPT female bulkhead with lock nut |
| Ferrule System | Double-ferrule CBC-Lok® |
| Material | 316 Stainless Steel |
| Body Hex Size | 5/8" |
| Length | 2.17" |
| Weight | 0.03 lbs |
| Series | DBHFP |
| Temperature Range | -20 °F to 1000 °F |
| Origin & Certification | Made in USA; ABS, ASTM A276/A182/A269, ASTM F1387, CRN, ISO 9001 |
